DLINK SWITCH DES-1210-28P 24PORT POE

Key Features:

1. 24 PoE Ports:
   • 24 x 10/100 Mbps Fast Ethernet ports.
   • Supports IEEE 802.3af PoE standard, delivering up to 15.4W per port.
   • Total PoE budget: 110W, which means it can power multiple PoE devices like IP cameras, VoIP phones, or wireless access points.
2. 4 Uplink Ports:
   • 4 x Gigabit Ethernet ports (10/100/1000 Mbps) for high-speed uplinks to servers or other switches.
3. Managed Switch:
   • Supports advanced features like VLAN, QoS, and IGMP snooping.
   • Provides network management via web interface, CLI, or SNMP.
4. Layer 2 Features:
   • VLAN (802.1Q) for network segmentation.
   • QoS (802.1p) for traffic prioritization.
   • IGMP snooping for efficient multicast traffic management.
5. PoE Management:
   • Allows you to monitor and control PoE power allocation.
   • Supports PoE scheduling to turn PoE on/off at specific times.
6. Energy-Efficient:
   • Complies with IEEE 802.3az Energy-Efficient Ethernet (EEE), reducing power consumption during low data activity.
7. Rack-Mountable:
   • Designed to fit in standard 19-inch racks.
8. Security Features:
   • Port security, MAC address filtering, and storm control to protect your network.
9. D-Link Green Technology:
   • Automatically adjusts power usage based on cable length and link status.

Use Cases:

• IP Surveillance: Power and connect multiple IP cameras.
• VoIP Networks: Power and connect VoIP phones.
• Wireless Networks: Power and connect wireless access points.
• Small Business Networks: Ideal for creating a managed network with PoE support.

Specifications:

• Switch Type: Managed Layer 2 Switch.
• PoE Standard: IEEE 802.3af.
• Total PoE Budget: 110W.
• Switching Capacity: 8.8 Gbps.
• MAC Address Table: 8K entries.
• Dimensions: 440 x 180 x 44 mm (17.32 x 7.09 x 1.73 inches).
• Weight: 3.2 kg (7.05 lbs).
