UBIQUITI POWERBEAM M2 400

Key Specifications

• Frequency Band: 2.4 GHz (2405–2475 MHz)

• Antenna Gain: 18 dBi

• Throughput: 150+ Mbps real TCP/IP throughput

• Range: 20+ km

• MIMO Configuration: 2×2 MIMO

• Networking Interface: 1 x 10/100 Mbps Ethernet port

• Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)

• Power Supply: 24V, 0.5A PoE adapter (Included)

• Max. Power Consumption: 6W

• Dimensions: 420 x 420 x 289 mm (16.5 x 16.5 x 11.4″)

• Weight: 1.8 kg (4 lb)

• Mounting: Pole mount kit included

• Operating Temperature: –40 to 70°C (-40 to 158°F)

• Operating Humidity: 5% to 95% noncondensing

• Certifications: FCC, IC, CE

• Enclosure Material: UV-stabilized plastic

• Wind Survivability: Up to 200 km/h (125 mph)

• Wind Loading: 342.5 N @ 200 km/h (77 lbf @ 125 mph)

Features

• InnerFeed Technology: Integrates the radio into the feedhorn of the antenna, eliminating the need for cables and reducing signal loss.

• airMAX TDMA Protocol: Enhances network performance and scalability by allowing each client to send and receive data using pre-designated time slots.

• Robust Design: Weather-resistant enclosure with UV stabilization and corrosion-resistant hardware ensures durability in harsh environments.

• Easy Installation: Includes a pole mount kit and features a built-in mechanical tilt for precise alignment.

Pros:

• Long-range connectivity suitable for remote areas.

• High-gain antenna for improved signal strength.

• Durable design withstands extreme weather conditions.

• Cost-effective solution for extending network coverage.
